Stone PC Case, Cooler Master GPU, DIY Case from Scratch, and Metal Fans
jimmy_thang
June 4, 2025
Cooler Master is doing some really interesting stuff with its new cases
The Highlights
- Cooler Master’s upcoming MF600, MF500, and MF400 reconfigurable frame cases are assembled from columns and corners
- The company also showed off interesting stone facade case front panels
- Cooler Master is working on a “GPU” with Asus
Table of Contents
Grab a
GN Tear-Down Toolkit to support our AD-FREE reviews and IN-DEPTH testing while also getting a high-quality,
highly portable 10-piece toolkit that was custom designed for use with video cards for repasting and water block installation. Includes a portable roll bag, hook hangers for pegboards, a storage compartment, and instructional GPU disassembly cards.
Intro
We visited Cooler Master’s booth at Computex 2025 where the company showed off several new cases. Arguably the most interesting one is a modular case. It comes with, we believe, 8 corners and 12 columns.
Editor's note: This was originally published on May 20, 2025 as a video. This content has been adapted to written format for this article and is unchanged from the original publication.
Credits
Host
Steve Burke
Camera, Video Editing
Mike Gaglione
Vitalii Makhnovets
Writing, Web Editing
Jimmy Thang
Cooler Master MF Cases
The case comes with a front panel that has a dust filter in it.
With it all assembled, it looks like the cases in the image above. The cases are the MF series, with the largest one being the MF600, which we assume translates to “Motherf***ing 600.” There’s also the MF500 and the smaller MF400.
Initially, Cooler Master is basically going to be selling pre-configured models. Eventually, the company wants to allow people to customize the case on their site and have it assembled and shipped from around the City of Industry. It’s pretty cool as it’s a fully modular approach.
The side panels are secured to the case via magnets, which is actually a nice touch.
Internally, the MF600 we saw came with 3x140mm fans on the front and 1x120mm fan on the back. The motherboard tray is pretty standard for the most part. Exceptions include a rail system that provides numerous holes for screws to go in, which allows Cooler Master to reconfigure things.
Inside the case towards the back, there’s also a rail system, which forms bits and pieces of the motherboard tray that allow for more customizability.
Cooler Master has been kind of on-and-off in the DIY space over the years where they’ve had some really big wins and some really big losses. They were also kind of absent for a while, but these MF cases represent a better showing from what we’ve seen in a while from the company.
According to Cooler Master, a pre-configured MF600 is supposed to cost $200. We expect to test and review the case.
The MF500 is supposed to go for $165 and includes 2x200mm fans in the front and 1x120mm fan in the back.
The smallest MF case, the MF600, which is a very large micro ATX box, is going for $150. In terms of fans, it has 2x120mm ones at the bottom coupled with a 1x120mm fan in the rear.
Cooler Master also showed off different panel types they’re experimenting with. One of them included a facade-style stone.
One of the pre-built MF cases we looked at had stuff flipped around in an inverted layout. One of the benefits of its rail system allows the case to have a bar that screws in which can support the GPU. Looking into this system, you can see that the PSU is at the bottom next to a bottom intake fan.
Updated Cosmos
Visit our
Patreon page to contribute a few dollars toward this website's operation (or consider a
direct donation or buying something from our
GN Store!) Additionally, when you purchase through links to retailers on our site, we may earn a small affiliate commission.
Cooler Master’s updated Cosmos has the NVIDIA-like DGX style front.
We also saw a variant of the Cosmos with thermal baffles in it. We have some criticisms of its execution, but overall, it’s an interesting idea.
The way the baffles are designed, Cooler Master is trying to bring air straight in through its channels. There’s a channel for the CPU that exposes the fin stack and Cooler Master's V8 CPU cooler. It conveys an idea similar to an engine cover.
The GPU has a separate baffle beneath the CPU one. The company is trying to isolate air flow. In theory, this should work well and we would love this idea applied to more affordable cases, like the MF series, especially since they’re already kind of configurable.
Looking at the back, fans can be mounted on the rear, which can help pull air out.
We also saw another variant of the Cosmos case running liquid cooling with a distro block. It was coupled with 4x180mm fans and a “720” radiator, which pulled air into the case. Unfortunately, the air is blowing straight into the wall of a motherboard tray, but Cooler Master says the plan is to pull the air up and out of the case with additional 180mm fans on the top and to move the PSU towards the bottom of the case.
Looking closer at the front of the special edition of the Cosmos cases, we can see the NVIDIA DGX shroud, which Cooler Master manufactures. It’s essentially like a sponge-like mesh.
The special edition of the Cosmos doesn’t have a price yet, but the non-special edition variant is supposed to be around $400, which is before any potential tariffs.
Cooler Master Coolers
Cooler Master showed off some CPU air coolers that had some 3D heat pipes, which had more heat pipes protruding from the center.
The company also showed off its V8 cooler and a full-metal fan. The fan’s blades and frame are both aluminum.
Cooler Master Elite Series Cases
Cooler Master does some really cool sh*t but has a branding problem. For instance, the company’s “Elite” series cases, shown in the image above, are actually budget cases. From left to right, we believe they are called the Elite 482 ($50), Elite 600 ($65), Elite 490 Wood ($50), Elite 691 Wood ($60), Elite 693 ($60), Elite 692 ($70), Elite 302 ($40), and Elite 502 ($60). Our advice to Cooler Master here is for them to unf*ck these names.
Most of the Elite series cases don’t come with fans with the exception of the Elite 302 and Elite 502, which come with 3 ARGB fans.
MF360
Next up are Cooler Master’s MF360 cases, which conveys that you can see inside the case from all sides. While it’s going to have some thermal challenges, to give the company credit, it’s actually really good looking.
The MF360 is a showcase fish-tank style PC that you can see through from both sides. Inside the case, we saw a distro block and tubes routed through on both sides.
Cooling X
The case in the image above, which goes by "Cooling X,” and uses the company’s new MF frame system. If you look at the corner, you can see the individual columns. At Computex, we saw it as a pre-built system.
The top of the case has a magnetically attached panel, which just pulls right off. The panel itself provides really good porosity and the material is pretty nice. Removing the top panel exposes 2 offset fans. The back fan tries to pull in air with the front fan trying to exhaust air out of the top, which is why they’re offset. That’s kind of cool to see.
Cooler Master Fans
Cooler Master showed off all-aluminum fans, which include the blades and frame. The MF120 XT is a 120mm model, is supposed to be $35, and the company says it goes up to 4,000 RPM.
The fan’s RPM can also be button-controlled via an external remote and it uses a dual-ball-bearing solution.
Cooler Master’s mixed fans, which use plastic blades coupled with an aluminum frame, come with fluid dynamic bearings (FDBs). The clearance between the fan blade tip and the frame is important as the smaller that clearance is, the better performance you get. The major downside is that as the fan ages, it can start to clip the interior of the frame. Having it too close can also negatively impact yields. The solution to this is LCP, which is incredibly expensive, or metal, because it doesn’t deform, but that’s also expensive. Right now, Cooler Master says it’s about a .8mm distance, which is pretty good. The company is targeting 0.6mm by the time the fan launches.
Cooler Master Video Card Shroud
Grab a
GN15 Large Anti-Static Modmat to celebrate our 15th Anniversary and for a high-quality PC building work surface. The Modmat features useful PC building diagrams and is anti-static conductive. Purchases directly fund our work! (or consider a
direct donation or a
Patreon contribution!)
Cooler Master also showed off some video cards, which is not something the company is typically involved with.
Cooler Master created a GPU shroud with adjustable slats that can accommodate 15-30mm fans. This solution is geared towards pre-built PCs and isn’t planned to be sold separately.
Examining one of the fans, we saw a standard 25mm-thick fan, which Cooler Master’s GPU shroud solution can adjust to via different notch options.
Cooler Master is also using a vapor chamber, which is supported by 8x8mm heat pipes running through the shroud and a gigantic fin stack. In total, it weighs almost 7 pounds (3.2 kilograms).
Cooler Master claims that, in terms of cooling, it performs similar to the 4-fan Astral solution at lower noise levels, but we don’t have those numbers.
With 4,000 RPM fans running on a 600-watt heat load, Cooler Master claims a 5090 will run at about 49 degrees C or so for the GPU.
